Model: NLK-2MP04
Parameter |
SPEC. |
|
Optical size Sensor |
1/2.7inch CMOS sensor |
|
Sensor Resolution |
1920(H) x 1080 (V),1080P |
|
Unit pixel size |
3*3um |
|
Color filter |
RGB Bayer pattern |
|
Shutter type |
Electronic Rolling Shutter |
|
Max.capture frame rate |
30fps@full resolution, |
|
Max. video frame rate |
30fps@VGA,30fps1080P |
|
View Angle9 |
0degree to 170degree |
|
F Number |
from 2.8 to 6mm normal lens |
|
AEC / AGC/ White Balance |
Auto |
|
Focus Distance |
with fixed lens 50CM-∝ |
|
Interface |
USB 2.0 |
|
Power |
USB Bus Power |
|
Dimensions (mm) (L x W x H) |
26.5mm x 23.5mm x27.5(include lens) +/-0.2mm |
|
Operating Temperature |
0℃to +50°C |
|
Operating System Request |
Windows XP/ Windows 7/ Windows 8(UVC), Linux(>V2.6 ) |
|
Max pixel rate |
28Mp/s |
|
ADC accuracy |
10-bit |
|
USB 2.0 PHY |
On Chip PHY |
|
Power Consumption |
Standby |
4mA |
Operating |
100mA士10mA @ 720P |
