High-Speed 2MP 1080P 120FPS WDR No-Distortion USB3.0 Global Shutter Camera Module for Motion Capture & Industrial Inspection-副本
Category：-8MP AF&Fixed Lens
Product specifications：
USB3.0 camera module Global shutter camera module Industrial camera module Machine vision camera 120fps camera UVC camera M12 lens camera High speed camera module Camera module for robotics
Details
| Items | Parameters |
| Image Sensor | 1/2.6-inch CMOS Sensor |
| Resolution | 1920 × 1200 Pixels |
| Data Format | MJPEG@1080P@120fps / YUV 1080P@60fps |
| Focus Mode | Fixed focus |
| Camera Controls | Saturation; Contrast; Sharpness |
| White Balance | Auto |
| Exposure | Auto |
| Power Supply | DC 5V |
| Working Current | < 180 mA |
| Storage Temperature | 0 °C to +60 °C |
| Operating Temperature | −20 °C to +75 °C |
| Driver Standard | UVC (Driver-free international standard) |
| System Compatibility | 1、 Windows XP SP2, Vista, Windows 7, Windows 8, Windows 8.1; 2、 Android and Linux embedded operating systems (via secondary development) |
| Interface | USB 3.2 Gen 1 |
| Grayscale Level | 8-bit |
| Still Image Format | BMP, JPG, etc. |
| Video Format | AVI / WMV |
| Microphone (MIC) | Digital silicon microphone (MIC) |
| API | Provided (for secondary development) |
| Decoding Software | Provided (mjpegcodecv v3.2.4) |
