Module No.

RS-S20LH234-V1.0.2

Module size (with shell)

45.46mm ×45.46mm ×22.10mm±0.3 mm

Module size (without shell)

32mm ×32mm × 14.6mm±0.3 mm

Temperature (Operation)

-20°C to 80°C

Temperature (Stable Image)

0°C to 60°C

Assembly technique

SMT (ROSH)

Focus

Fix

PCB printing ink

black

interface

USB 2.0

Power

USB bus power 5V

Power Consumption

RGB:80mA±5%@5V

Operating system request

Windows 2000/XP/7/8/8. 1/10,Linux ，Android

Sensor Type

RGB

Active Array Size

1920*1080

Sensitivity

3.24V/ Lux-sec

Maximum Image Transfer Rate

30fps (1920*1080)

Pixel Size

2.7um*2.7um

S/N Ratio

37dB

Dynamic Range

74dB

Lens Type

Lens Construction

650nm

F/No

2.5

EFL

1.5

FOV

190° ±5°

HORIZONTAL

190°±5°

VERTICAL

143°±5°

TV Distortion

<-17.5%

IR Filter

650nm

DSP Type

AGC/AEC/Whiter balance

Auto

Output Formats

Mjpeg/FPS

YUY2/FPS

1920*1080 @30fps

1280*1024 @30fps

1280*960 @30fps

1280*720 @30fps

920*1080 @30fps

1024*768@30fps 800*600 @30fps

640*480 @30fps

320*240 @30fps

640*480 @30fps

Fixed Pattern Noise

< 0.03%          of    VPEAK-TO-PEAK
